Electric Sliding Gate Motors

Electric Sliding Gate Motors Specification

Voltage
220 V

Torque
9 Nm

Features
Remote Controlled, Automatic Stop on Obstruction, Manual Override, Corrosion Resistant

Rated Frequency
50 Hz

Rated Voltage
220 V

Bearing Type
Ball Bearing

Motor Type
Induction Motor

Starting Type
Electric Start

Current Type
AC

Pressure
Standard atmospheric

Ambient Temperature
-20C to 50C

Horse Power
0.5 HP

Cooling Method
Air Cooled

Noise Level
56 dB

Power Rating
370 W

Poles Number
4

Efficacy
High

Product Type
Electric Sliding Gate Motor

Output Power
370 W

Frequency (MHz)
50 Hz

Protect Feature
Overload protection

Phase
Single Phase

Speed
1400 rpm

Power
370 Watts

Color
Grey/Black

Dimension (L*W*H)
290 x 240 x 180 mm

Weight
10 kg

Shaft Diameter
12 mm

Mounting Type
Base Mounted

IP Rating
ip44

Safety Functions
Obstacle Detection, Auto Stop & Reverse

Duty Cycle
60% (S3)

Operating Humidity
90% RH

Control Board
Integrated

Maximum Gate Weight
600 kg

Opening/Closing Time
12 m/min

Remote Control Range
Up to 30 meters

Limit Switch Type
Magnetic

Electric Sliding Gate Motors Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
1 Week

About Electric Sliding Gate Motors

Clearance alert: select from our dazzling range of Electric Sliding Gate Motors, renowned for their formidable performance and now available at the lowest priceending soon! Designed for gates up to 600 kg, these motors feature a remote control range of 30 meters and achieve a brisk opening speed of 12 meters per minute. With integrated control boards, magnetic limit switches, and advanced obstacle detection with auto stop & reverse, safety is paramount. Robust, air-cooled induction motors deliver 370 W power. Corrosion-resistant, humidity & temperature tolerant, and IP44 ratedideal for the demanding commercial and domestic Indian market.

Versatile Usage & Applications of Electric Sliding Gate Motors

Electric Sliding Gate Motors are widely used in commercial, industrial, and residential settings across India. Renowned facility managers, security providers, and property developers select these motors for their reliable automation of security gates. Their formidable build and dazzling efficiency make them ideal for corporate parks, warehouses, residential complexes, and retail outlets, ensuring controlled access, enhanced security, and seamless daily operations. Designed for both new installations and retrofits, they serve gate operators, traders, and service providers nationwide.

Packaging, Export Markets & Certifications at the Lowest Price Offer

Our Electric Sliding Gate Motors are securely packaged to protect them during transit, ensuring safe delivery every time. Benefit from our limited-time offerending soonfor the domestic market and select global markets. We supply to major exporters, traders, and service providers across India at the lowest price. Each unit comes with necessary certifications, reinforcing trusted quality and compliance for both domestic and international use. Dont miss this opportunity to invest in certified, robust automation solutions.

FAQs of Electric Sliding Gate Motors:

Q: How do the obstacle detection and auto stop & reverse functions enhance safety?

A: These functions automatically detect obstructions during operation, promptly halting and reversing the gate to prevent accidents or damage, prioritizing user and property safety.

Q: What is the maximum weight capacity for these Electric Sliding Gate Motors?

A: The motors are engineered to handle gates weighing up to 600 kg, making them suitable for a wide range of residential and commercial applications.

Q: Where can I use these gate motors for optimal efficiency?

A: They are ideal for residential complexes, commercial estates, warehouses, and retail locationsanywhere requiring secure and automated gate access.

Q: What process is involved in installing the sliding gate motor?

A: Installation typically involves mounting the motor base, integrating the magnetic limit switch, connecting to a power supply (220V AC), and configuring the remote control system. Professional installation is recommended.

Q: When should I select the magnetic limit switch type?

A: Select the magnetic limit switch type when precise, contactless end-position detection is required for efficient and low-maintenance gate operation.

Q: What are the packaging details and export options for these motors?

A: Each motor is packed in robust materials for safety during shipment, suitable for supply in the domestic market and selected international regions, complete with all required certifications.
